BLOG

Your 10/40/100G Network Is More Susceptible To Data Breaches

June 17, 2015

Since when did greater network capacity mean greater risk of data breaches?

The truth? This has always been the case. But, the transformation of how we operate online and the rapid growth from 10G to 40G to 100G have magnified the problem.

In 2015, users are browsing the Web and watching videos far more than they used to. They’re also using a seemingly countless number of new applications. These activities eat into your bandwidth, necessitating the move to bigger, faster networks.

With greater network utilization and the transmission of more data, you’re more susceptible to network and data breaches.

What Makes A Data Breach More Likely On Your Network?

Data capture is fundamental to thwarting breaches and other network security issues. You must have complete visibility into the critical, more vulnerable areas of your network. With so much traffic passing through different areas of your network, data capturing tools are often overwhelmed, dropping packets of critical information. If your forensic and analysis tools are missing critical data, how can you expect them to do their jobs completely and give you the insight you need?

A security device’s hardware and software may not be able to keep up with your network speed. For example, based on how its software is written, a 10G analyzer can only support 2G of traffic.

You must be capable of analyzing and inspecting your traffic to pinpoint network security issues. But, the more data you have, the harder it is to collect it all.

How Do You Know If Your Network Can Handle The Data?

A big data network that transmits scores of packets doesn’t have to remain vulnerable to data breaches.

Many organizations rely on switches and their SPAN ports to copy network traffic, but SPAN is an incredible weakness for network security. Its inability to handle much data is a huge cause for packets being dropped.

In fact, Cisco recommends that its customers avoid using its switches for data collection on 10/40/100G networks.

On the other hand, if you’ve placed network TAPs at different areas of your network, you guarantee complete data capture and the ability to see attempted data breaches.

Network TAPs ensure that your security devices get the data they need to perform. For example, tapping inside of your security perimiter gives you complete visibility into any data leakage, empowering you to pinpoint the problem.

Considering The Cost Of Data Breaches And Fortifying Your Security

Let’s face it: Cost is a big component of network conversations. Companies buy 40G networks because they’ve become so cheap. A consequence of the transition, however, is your slower (and expensive) tools’ inability to handle the influx of data.

Many consultants recommend purchasing an additional security analyzer and balancing traffic between the two tools to guarantee security. But, a 10G analyzer will cost you $100,000.

Rather than buying a second analyzer, leverage load balancers – network TAPs that are “session aware” and that slice and dice data to allow only pertinent data through to a single analyzer.

The reality is that security tools will always lag behind network speeds and data capacity. Bigger data networks are introduced to the market, and then updated devices are developed.

With 400G networks already in discussion, it’s imperative that you have a way to not only protect your network from data breaches, but also protect your significant investment in security tools.

Learn more about ensuring the transmission of critical data to your security tools and protecting your network.

New Call-to-action



See Everything. Secure Everything.

Contact us now to secure and optimized your network operations

Heartbeats Packets Inside the Bypass TAP

If the inline security tool goes off-line, the TAP will bypass the tool and automatically keep the link flowing. The Bypass TAP does this by sending heartbeat packets to the inline security tool. As long as the inline security tool is on-line, the heartbeat packets will be returned to the TAP, and the link traffic will continue to flow through the inline security tool.

If the heartbeat packets are not returned to the TAP (indicating that the inline security tool has gone off-line), the TAP will automatically 'bypass' the inline security tool and keep the link traffic flowing. The TAP also removes the heartbeat packets before sending the network traffic back onto the critical link.

While the TAP is in bypass mode, it continues to send heartbeat packets out to the inline security tool so that once the tool is back on-line, it will begin returning the heartbeat packets back to the TAP indicating that the tool is ready to go back to work. The TAP will then direct the network traffic back through the inline security tool along with the heartbeat packets placing the tool back inline.

Some of you may have noticed a flaw in the logic behind this solution!  You say, “What if the TAP should fail because it is also in-line? Then the link will also fail!” The TAP would now be considered a point of failure. That is a good catch – but in our blog on Bypass vs. Failsafe, I explained that if a TAP were to fail or lose power, it must provide failsafe protection to the link it is attached to. So our network TAP will go into Failsafe mode keeping the link flowing.

Glossary

  1. Single point of failure: a risk to an IT network if one part of the system brings down a larger part of the entire system.

  2. Heartbeat packet: a soft detection technology that monitors the health of inline appliances. Read the heartbeat packet blog here.

  3. Critical link: the connection between two or more network devices or appliances that if the connection fails then the network is disrupted.
